代码来自于一篇博客,用tensorflow判断拨号图标和短信图标的分类,训练已经成功运行,以下为测试代码,错误出现在38行
image = tf.reshape(image, [1, 208, 208, 3])
我的测试图片是256*256的,也测试了48*48的
#!/usr/bin/python
# -*- coding:utf-8 -*-
# @Time : 2018/3/31 0031 17:50
# @Author : scw
# @File : main.py
# 进行图片预测方法调用的文件
import numpy as np
from PIL import Image
import tensorflow as tf
import matplotlib.pyplot as plt
from shenjingwangluomodel import inference
# 定义需要进行分类的种类,这里我是进行分两种,因为一种为是拨号键,另一种就是非拨号键
CallPhoneStyle = 2
# 进行测试的操作处理==========================
# 加载要进行测试的图片
def get_one_image(img_dir):
image = Image.open(img_dir)
# Image.open()
# 好像一次只能打开一张图片,不能一次打开一个文件夹,这里大家可以去搜索一下
plt.imshow(image)
image = image.resize([208, 208])
image_arr = np.array(image)
return image_arr
# 进行测试处理-------------------------------------------------------
def test(test_file):
# 设置加载训练结果的文件目录(这个是需要之前就已经训练好的,别忘记)
log_dir = '/home/administrator/test_system/calldata2/'
# 打开要进行测试的图片
image_arr = get_one_image(test_file)
with tf.Graph().as_default():
# 把要进行测试的图片转为tensorflow所支持的格式
image = tf.cast(image_arr, tf.float32)
# 将图片进行格式化的处理
image = tf.image.per_image_standardization(image)
# 将tensorflow的图片的格式参数,转变为shape格式的,好像就是去掉-1这样的列表
image = tf.reshape(image, [1, 208, 208, 3])
# print(image.shape)
# 参数CallPhoneStyle:表示的是分为两类
p = inference(image, 1, CallPhoneStyle) # 这是训练出一个神经网络的模型
# 这里用到了softmax这个逻辑回归模型的处理
logits = tf.nn.softmax(p)
x = tf.placeholder(tf.float32, shape=[208, 208, 3])
saver = tf.train.Saver()
with tf.Session() as sess:
# 对tensorflow的训练参数进行初始化,使用默认的方式
sess.run(tf.global_variables_initializer())
# 判断是否有进行训练模型的设置,所以一定要之前就进行了模型的训练
ckpt = tf.train.get_checkpoint_state(log_dir)
if ckpt and ckpt.model_checkpoint_path:
# global_step = ckpt.model_checkpoint_path.split('/')[-1].split('-')[-1]
saver.restore(sess, ckpt.model_checkpoint_path)
# 调用saver.restore()函数,加载训练好的网络模型
print('Loading success')
else:
print('No checkpoint')
prediction = sess.run(logits, feed_dict={x: image_arr})
max_index = np.argmax(prediction)
print('预测的标签为:')
if max_index == 0:
print("是拨号键图片")
else:
print("是短信图片")
# print(max_index)
print('预测的分类结果每种的概率为:')
print(prediction)
# 我用0,1表示两种分类,这也是我在训练的时候就设置好的
if max_index == 0:
print('图片是拨号键图标的概率为 %.6f' %prediction[:, 0])
elif max_index == 1:
print('图片是短信它图标的概率为 %.6f' %prediction[:, 1])
# 进行图片预测
test('/home/administrator/Downloads/def.png')
'''
# 测试自己的训练集的图片是不是已经加载成功(因为这个是进行训练的第一步)
train_dir = 'E:/tensorflowdata/calldata/'
BATCH_SIZE = 5
# 生成批次队列中的容量缓存的大小
CAPACITY = 256
# 设置我自己要对图片进行统一大小的高和宽
IMG_W = 208
IMG_H = 208
image_list,label_list = get_files(train_dir) # 加载训练集的图片和对应的标签
image_batch,label_batch = get_batch(image_list,label_list,IMG_W,IMG_H,BATCH_SIZE,CAPACITY) # 进行批次图片加载到内存中
# 这是打开一个session,主要是用于进行图片的显示效果的测试
with tf.Session() as sess:
i = 0
coord = tf.train.Coordinator()
threads = tf.train.start_queue_runners(coord=coord)
try:
while not coord.should_stop() and i < 2:
# 提取出两个batch的图片并可视化。
img, label = sess.run([image_batch, label_batch])
for j in np.arange(BATCH_SIZE):
print('label: %d' % label[j])
plt.imshow(img[j, :, :, :])
plt.show()
i += 1
except tf.errors.OutOfRangeError:
print('done!')
finally:
coord.request_stop()
coord.join(threads)
'''
