[Filebeat-3.9.3]Custom module for Filebeat and Wazuh

Question

Overview

From the Beats docs:

Each Filebeat module is composed of one or more "filesets". We usually create a module for each service that we support (nginx for Nginx, mysql for Mysql, and so on) and a fileset for each type of log that the service creates. For example, the Nginx module has access and error filesets. You can contribute a new module (with at least one fileset), or a new fileset for an existing module.

Why does Wazuh need a Filebeat module?

Here is a list of issues we are working on it but may be solved using a custom Filebeat module:

• Problems indexing rotated events or Filebeat is stopped more than one day https://github.com/wazuh/wazuh-documentation/issues/1269
• Workarounds about the GeoIP features, renaming fields, ingest pipelines https://github.com/wazuh/wazuh/issues/3512
• Problems with the full_log field, JSON formats, mapping conflicts https://github.com/wazuh/wazuh/issues/3513

In addition, most of the logic we are doing in configuration files, pipelines and some other files can be achieved using a custom module for Filebeat.

Creating the module

1. The first step is to learn about Filebeat modules, the reference docs are https://www.elastic.co/guide/en/beats/devguide/current/filebeat-modules-devguide.html, where we can find useful information on how to create a simple module.
2. Once we know how to create the module, we can start to migrate all the Wazuh related logic to this module.

Tasks - [x] Researching about Filebeat modules. - [x] Implement a simple module to apply acquired knowledge. - [x] Design and decide what our module should do for us. - [x] Implement the module, test the module against different use cases. - [x] Create/update the proper documentation. - [ ] Should we try to publish it as an official Filebeat module (their website)?

该提问来源于开源项目：wazuh/wazuh

Answer 1

Getting started with Filebeat modules

Following the how-to docs from the Elastic docs, I've created the very first Filebeat module for testing purposes.

Since it needs "Go" to be installed, I've installed it as follow (using 1.11.5 because is the version for beats v7.1.1):

sh
GO_VERSION="1.11.5"
curl -so go.tar.gz "https://dl.google.com/go/go$GO_VERSION.linux-amd64.tar.gz"
tar -xzf go.tar.gz
mv go /usr/local/
rm -f go.tar.gz

Setup Go environment:

sh
export GOROOT=/usr/local/go
export GOPATH=/home/vagrant/filebeat-wazuh-module
export PATH=$GOPATH/bin:$GOROOT/bin:$PATH
go version
// go version go1.11.5 linux/amd64

Prepare Filebeat:

sh
go get github.com/elastic/beats
cd src/github.com/elastic/beats/filebeat/
git checkout v7.1.1
go get
make

Create an empty module:

sh
make create-module MODULE=wazuh
// New module was generated, now you can start creating filesets by create-fileset command.

Verify the generated empty module:

tree module/wazuh/
module/wazuh/
├── _meta
│   ├── config.yml
│   ├── docs.asciidoc
│   └── fields.yml
└── module.yml

Now, create the fileset for the module:

make create-fileset MODULE=wazuh FILESET=wazuh-fileset
New fileset was generated, please check that module.yml file have proper fileset dashboard settings. After setting up Grok pattern in pipeline.json, please generate fields.yml

Verify the generated fileset for the Wazuh module:

├── _meta
│   ├── config.yml
│   ├── docs.asciidoc
│   └── fields.yml
├── module.yml
└── wazuh-fileset
    ├── config
    │   └── wazuh-fileset.yml
    ├── ingest
    │   └── pipeline.json
    ├── manifest.yml
    ├── _meta
    └── test

After doing a tiny modification in the manifest.yml, I've tried to build the module, then I've noticed virtualenv is also needed.

yum install python-virtualenv -y

Now, and following their docs:

make update
mage update
Generated fields.yml for filebeat to /home/vagrant/filebeat-wazuh-module/src/github.com/elastic/beats/filebeat/fields.yml
No fields files for module apache2
Generated fields.yml for filebeat to /home/vagrant/filebeat-wazuh-module/src/github.com/elastic/beats/filebeat/fields.yml
>> Building filebeat.yml for linux/amd64
>> Building filebeat.reference.yml for linux/amd64
>> Building filebeat.docker.yml for linux/amd64
Generated fields.yml for filebeat to /home/vagrant/filebeat-wazuh-module/src/github.com/elastic/beats/filebeat/build/fields/fields.all.yml

Load the fake module into Filebeat:

1. First step is to stop Filebeat and to modify its current configuration.

sh
systemctl stop filebeat
vi /etc/filebeat/filebeat.yml

Here is the testing config I've used:

yaml
filebeat.modules:
- module: wazuh

output.elasticsearch.hosts: ['http://172.16.1.4:9200']
output.elasticsearch.indices:
  - index: 'testing-module'

Copy our module to Filebeat:

sh
cp modules.d/wazuh.yml.disabled /etc/filebeat/modules.d/
cp module/wazuh/ /usr/share/filebeat/module/ -R
stat -c "%a %n" /usr/share/filebeat/module/zeek # Not needed, just looking for the right perms (755)
chmod 755 /usr/share/filebeat/module/wazuh -R

Run Filebeat in debug mode:

/usr/share/filebeat/bin/filebeat -e -c /etc/filebeat/filebeat.yml -path.home /usr/share/filebeat -path.config /etc/filebeat -path.data /var/lib/filebeat -path.logs /var/log/filebeat -d '*'

Add an alert to the alerts.json:

cat myalert.json >> /var/ossec/logs/alerts/alerts.json

And here is the Filebeat output (reduced because the debug messages are too long):

[root filebeat]# cat /tmp/output.txt | grep wazuh
    "pipeline": "filebeat-7.1.0-wazuh-wazuh-fileset-pipeline"
    "type": "wazuh"
  "message": "{\"timestamp\":\"2019-06-11T08:29:26.125+0000\",\"rule\":{\"level\":3,\"description\":\"Service startup type was changed\",\"id\":\"61104\",\"info\":\"This does not appear to be logged on Windows 2000\",\"firedtimes\":2,\"mail\":false,\"groups\":[\"windows\",\" windows_systempolicy_changed\"],\"pci_dss\":[\"10.6\"],\"gdpr\":[\"IV_35.7.d\"]},\"agent\":{\"id\":\"010\",\"name\":\"windows-ag\",\"ip\":\"10.0.2.15\"},\"manager\":{\"name\":\"master\"},\"id\":\"1560241766.129973\",\"cluster\":{\"name\":\"wazuh\",\"node\":\"node01\"},\"decoder\":{\"name\":\"windows_eventchannel\"},\"data\":{\"foo\":\"bar\"},\"location\":\"EventChannel\"}",
    "module": "wazuh",
    "dataset": "wazuh.wazuh-fileset"
    "name": "wazuh-fileset"
2019-06-24T15:36:27.186Z    DEBUG   [elasticsearch] elasticsearch/client.go:752 GET http://172.16.1.4:9200/_ingest/pipeline/filebeat-7.1.0-wazuh-wazuh-fileset-pipeline  <nil>
2019-06-24T15:36:27.187Z    DEBUG   [modules]   fileset/pipelines.go:120    Pipeline filebeat-7.1.0-wazuh-wazuh-fileset-pipeline already loaded
</nil>

As we can see our pipeline is doing the basic job, the event is not wazuh-comptaible yet of course, but it's a first step that I think is useful.

It's in Elasticsearch, and we can see it was indexed in the right index (testing-module):
