LED tutorial

As discussed in #1217, it might be nice to have a tutorial with e.g. a 2d LED-like structure with a thin (1d) light-emitting layer, showing several ways to solve it:

  1. Brute force: just a layer of random dipole emitters. By linearity, we can make them white noise and then scale by a desired spectrum later. (Similar to Alejandro's first near-field heat-transfer paper.) You'll need lots of simulations (and/or a long time) to get the spectrum to good accuracy (low variance).

  2. Better: since the dipoles are uncorrelated, we can just do a sequence of deterministic calculations, with one dipole at a time, for dipoles at different points — uncorrelated dipoles at different points just add their powers. So, you compute the powers and (suitably normalized, similar to how LDOS is normalized) add them up, scaling by the desired spectrum.

We could mention other techniques:

  1. Even better: instead of summing dipoles, we could use a different set of basis functions, e.g. a cosine series. See Alex McCauley's Casimir FDTD paper.

  2. Even better, for the case of volumetric emitters: use Alejandro and Homer's tricks to transform a volume of emitters into equivalent surface emitters. Or just use SCUFF.

For example, you could look at a structure like this one:


but with all widths W equal so that it's periodic. Compute the emission in the normal direction by treating the emitting layer as infinitesimally thin. This allows you to model a single unit cell with periodic (k=0) boundary conditions. (Emission into other directions can be computed by changing k.)

该提问来源于开源项目:NanoComp/meep

  • 点赞
  • 写回答
  • 关注问题
  • 收藏
  • 复制链接分享
  • 邀请回答

26条回答

  • weixin_39933713 weixin_39933713 4月前

    Yes; changing the origin of the source solved it.

    method2_3_res50_nfreq500_nsrc10_normalized_spectra

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Initial results comparing Method 2 and 3 for the 2d LED structure from above. Method 2 involves 55 single dipole calculations (resolution*L where resolution=50, L=1.1) which takes about 3.5 hours (for the flat/textured surface). Method 3 involves N=10 calculations with line sources having an amplitude function based on a cosine series (using the formula for fn(x) in the Casimir tutorial) which takes about 0.6 hours. The source time profile is identical in both cases (Gaussian pulse) and the runtime is 2/frequency resolution (same as before).

    method2_3_res50_nfreq500_nsrc10_normalized_spectra

    The agreement between Method 2 and 3 is not as good as it was between Method 1 and 2 shown previously. The Method 3 results are converged for N=10 as shown in the plot below for N=5, 10, and 20.

    method3_res50_nfreq500_normalized_spectra

    It is possible (but unlikely) that results for Method 2 are still not converged with respect to the runtime of 2/frequency resolution. Should we try increasing the resolution?

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    The source used for Method 3:

    py
    def src_amp_func(n):
        def _src_amp_func(p):
            if n == 0:
                return 1/np.sqrt(sx)
            else:
                return np.sqrt(2/sx) * np.cos(n*np.pi*p.x/sx)
        return _src_amp_func

    def compute_flux(n):
        sources = [mp.Source(mp.GaussianSource(fcen,fwidth=df),
                             component=mp.Ez,
                             center=mp.Vector3(0,-0.5*sy+dAg+0.5*dsub),
                             size=mp.Vector3(sx,0),
                             amp_func=src_amp_func(n))]

        sim = mp.Simulation(cell_size=cell_size,
                            resolution=resolution,
                            k_point=mp.Vector3(),
                            boundary_layers=pml_layers,
                            geometry=geometry,
                            sources=sources)

        flux_mon = sim.add_flux(fcen,df,nfreq,mp.FluxRegion(center=mp.Vector3(0,0.5*sy-dpml),size=mp.Vector3(sx)))
        sim.run(until_after_sources=run_time)
        flux = mp.get_fluxes(flux_mon)
        freqs = mp.get_flux_freqs(flux_mon)

        return freqs, flux


    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    I think you have an origin problem. In the Casimir case and in the Fourier cosine series as it is conventionally written, i.e. cos(πx/L) is define so that x=[0,L] … i.e. x=0 corresponds to the edge of the source, not the center.

    So, you just need to change p.x to p.x + sx/2 in your amplitude function.

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Increasing the runtime for method 2 does indeed improve the resolution of the sharp peaks. The agreement with method 1 is now much better.

    method1_2_res50_nfreq501_ndipole10_normalized_spectra

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    It would be nice to add a tutorial comparing method 2 to method 3.

    That is, you have a line of length L of uncorrelated emitters.

    1. In method 2, you would use L*resolution point sources, one per pixel.

    2. In method 3, you would use a sequence of line sources with cosine amplitude functions, exactly as described in the "Sources" section of the Casimir tutorial, for n=0, 1, 2,…,N

    In both cases, you add up the powers from each simulation.

    In method 3, keep doubling N until the answer stops changing to a desired tolerance, e.g. < 1%. You should find that N is essentially independent of resolution, in contrast to method 2 where the number of sources increases with resolution.

    To start with, you could normalize against a flat surface as before. However, if you normalize the cosine terms correctly (I think the same as in Alex McCauley's notes), I think you should find that you obtain the same absolute sum even without normalizing. (Well, there is also probably a factor of resolution that you have to multiply by in the point-source sum.)

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    (If the line sources are periodic, I think it should be even more efficient to use a sine+cosine Fourier-series basis rather than a cosine-only basis. But we can do cosines to start with since they are more generic.)

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Based on the results shown below, it seems we can demonstrate fairly good agreement between method 1 and 2. It's likely that the sharp peaks/dips for method 1 are simply an artifact of the number of random trials (500) and the agreement can be improved further by using an even larger number of trials. Because the flux spectra for the textured surface is normalized relative to the flat surface, there is no need for additional scaling in post processing.

    method1_2_normalized_spectra

    For now, the results we have compiled thus far should be sufficient for the tutorial. The next step is to add the results for methods 3 and 4.

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    Is it converged with runtime for method 2? You might need a longer run to resolve those sharp peaks.

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    (If we eventually want to show the cosine-series method, there should be one dipole per pixel along the source line, so that the number of dipoles increases with resolution.)

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    The following are three sets of results (10, 50, and 320 trials) for the normalized flux (textured/flat) on a semilogy plot. The fuzziness is reduced with increasing number of trials but the changes are not so significant.

    normalized_trials

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Using normalization approach 1, these are the results for the flat and textured emitters averaged over 500 random trials separately (i.e., the denominator and numerator).

    flat method1_flat_res50_nfreq501_ndipole10_ntrial500

    textured

    method1_textured_res50_nfreq501_ndipole10_ntrial500

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    What are you normalizing against? A homogeneous medium?

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    If you look carefully, you can see some bumpiness. It might be instructive to show the spectra for 100 trials superimposed underneath the 500-trial curve.

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Switching to a CustomSrc and running for 2/(frequency resolution) as well as increasing the number of trials to 500 (which required 3 days to run) makes the spectral peaks more pronounced with practically no noise or "fuzziness":

    py
        sources = []
        for n in range(ndipole):
            sources.append(mp.Source(mp.CustomSource(src_func=lambda t: np.random.randn()),
                                     component=mp.Ez,
                                     center=mp.Vector3(sx*(-0.5+n/ndipole),-0.5*sy+dAg+0.5*dglass)))
        ...
        ...
        ...
        flux_mon = sim.add_flux(fcen,df,nfreq,mp.FluxRegion(center=mp.Vector3(0,0.5*sy-dpml),size=mp.Vector3(sx)))
        run_time = 2*nfreq/df
        sim.run(until=run_time)


    method1_res50_nfreq501_ndipole10_ntrial500

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    You definitely want normalization 1, not normalization 2. You want to divide the ensemble-averaged fields. (And no need for the random numbers to be the same in F and F0.)

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    After increasing the number of frequencies by nearly a factor of 10 (from 51 to 501), two comments on the results shown below:

    1. the noisy spectrum of method 1 is not apparent and increasing the runtime did not the change results significantly
    2. the spectra from the two methods still differ by an overall scale factor even though both sets of results are normalized relative to the flat surface termination.

    method1_res50_nfreq501_ndipole10_ntrial200

    method2_res50_nfreq501_ndipole10

    Perhaps we need to go to an even finer frequency discretization and look at a narrower bandwidth in order to resolve the tiny fluctuations?

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    Probably you need a much longer runtime (~ 1/frequency resolution) to see the noise in the monte-carlo spectrum.

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    I think there was a misunderstanding, in method 1, you need white-noise sources. Every timestep for every dipole should be an independent random number.

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    That is, something like CustomSrc(src_func=lambda t: np.random.randn()) for each dipole. (Real fields is fine.)

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Two questions regarding the implementation strategy for method 1 (random dipoles).

    Q1 There are two different ways to perform the normalization given the flux spectrum for the flat surface (F0) and corrugated surface (F) over n trials: 1. (Σₙ F) / (Σₙ F0) 2. Σₙ (F / F0)

    These two approaches do not appear to be equivalent. Thus far, I've been using (2). Is this correct?

    (The same normalization approach is used for method 2.)

    Q2 For a given trial, are we supposed to use the same random source to compute F and F0? If so, this would require storing the random numbers from the first run involving F0 and then reusing them to compute F. Thus far, F and F0 are computed using a unique (randomly generated) CustomSource.

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    A comparison of the nondimensionalized spectra for (1) and (2) shows that, aside from a couple of extra peaks in (1) even when using 200 random trials, they are similar and differ by an overall constant factor. The number of dipoles as well their locations is the same in both methods.

    To obtain exact agreement, perhaps (1) requires an even larger number of random trials (i.e. >> 200 which already takes a few hours) and/or a different uncorrelated random number generator than random.random()?


    import meep as mp
    from meep.materials import Ag

    import numpy as np
    import random

    import matplotlib
    matplotlib.use('agg')
    import matplotlib.pyplot as plt

    import argparse
    parser = argparse.ArgumentParser()
    parser.add_argument('-res', type=int, default=50, help='resolution')
    parser.add_argument('-nd', type=int, default=10, help='number of dipoles')
    args = parser.parse_args()

    resolution = args.res

    dpml = 1.0
    dair = 1.0
    hrod = 0.7
    wrod = 0.5
    dglass = 5.0
    dAg = 0.5

    sx = 1.1
    sy = dpml+dair+hrod+dglass+dAg

    cell_size = mp.Vector3(sx,sy)

    pml_layers = [mp.PML(direction=mp.Y,
                         thickness=dpml,
                         side=mp.High)]

    fcen = 1.0
    df = 0.2
    nfreq = 51

    geometry = [mp.Block(material=mp.Medium(index=3.45),
                         center=mp.Vector3(0,0.5*sy-dpml-dair-0.5*hrod),
                         size=mp.Vector3(wrod,hrod,mp.inf)),
                mp.Block(material=mp.Medium(index=3.45),
                         center=mp.Vector3(0,0.5*sy-dpml-dair-hrod-0.5*dglass),
                         size=mp.Vector3(mp.inf,dglass,mp.inf)),
                mp.Block(material=Ag,
                         center=mp.Vector3(0,-0.5*sy+0.5*dAg),
                         size=mp.Vector3(mp.inf,dAg,mp.inf))]

    geometry_ref = [mp.Block(material=mp.Medium(index=3.45),
                             center=mp.Vector3(0,0.5*sy-dpml-dair-hrod-0.5*dglass),
                             size=mp.Vector3(mp.inf,dglass,mp.inf)),
            mp.Block(material=Ag,
                             center=mp.Vector3(0,-0.5*sy+0.5*dAg),
                             size=mp.Vector3(mp.inf,dAg,mp.inf))]

    def compute_flux(n,ndipole):
        sources = [mp.Source(mp.GaussianSource(fcen,fwidth=df),
                             component=mp.Ez,
                             center=mp.Vector3(sx*(-0.5+n/ndipole),-0.5*sy+dAg+0.5*dglass))]

        sim = mp.Simulation(cell_size=cell_size,
                resolution=resolution,
                k_point=mp.Vector3(),
                boundary_layers=pml_layers,
                geometry=geometry_ref,
                sources=sources)

        flux_mon = sim.add_flux(fcen,df,nfreq,mp.FluxRegion(center=mp.Vector3(0,0.5*sy-dpml),size=mp.Vector3(sx)))
        sim.run(until_after_sources=500)
        flux_ref = mp.get_fluxes(flux_mon)

        sim.reset_meep()

        sim = mp.Simulation(cell_size=cell_size,
                            resolution=resolution,
                            k_point=mp.Vector3(),
                            boundary_layers=pml_layers,
                            geometry=geometry,
                            sources=sources)

        flux_mon = sim.add_flux(fcen,df,nfreq,mp.FluxRegion(center=mp.Vector3(0,0.5*sy-dpml),size=mp.Vector3(sx)))
        sim.run(until_after_sources=500)
        flux = mp.get_fluxes(flux_mon)
        freqs = mp.get_flux_freqs(flux_mon)

        flux_norm = [f/f_ref for f_ref,f in zip(flux_ref,flux)]
        sim.reset_meep()

        return freqs, flux_norm

    ndipole = args.nd
    fluxes = np.zeros((nfreq,ndipole))

    for n in range(ndipole):
        freqs, fluxes[:,n] = compute_flux(n,ndipole)

    flux_sum = np.sum(fluxes,axis=1)

    if mp.am_master():
        plt.figure()
        plt.plot(freqs,flux_sum,'bo-')
        plt.xlabel('frequency')
        plt.ylabel('flux in +y direction (relative to flat interface)')
        plt.title('resolution: {}, num. dipoles: {}'.format(resolution,ndipole))
        plt.savefig('led_method2_res{}_ndipole{}.png'.format(resolution,ndipole))

    for n in range(nfreq):
        print("flux:, {}, {}".format(freqs[n],flux_sum[n]))


    method 1: random dipoles led_method1_res50_ndipole10_ntrial200

    method 2: individual dipoles

    led_method2_flux_res50_ndipole10

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    Probably you should use a finer frequency discretization so that it is clear that in the individual-dipole case you have a smooth spectrum whereas in the stochastic case you have a noisy spectrum (the real spectrum multiplied by white noise).

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    (It's only when you average over a large enough ensemble that the noise variance will become small. Note you'll need to run for a long enough time for the DFT spectrum to resolve these oscillations.)

    点赞 评论 复制链接分享
  • weixin_39933713 weixin_39933713 4月前

    Some initial results for the brute-force approach described in (1). The calculation involves computing the upward flux in a 2d unit cell for a structure similar to that shown above. The setup is shown in the schematic below. The source consists of 10 individual dipole emitters with random complex amplitude (unit magnitude) placed along a line in the emitting layer (red dots). There is a Ag back reflector below the emitter layer so that all the flux is reflected upwards (+y). The flux spectrum is averaged over N separate runs and seems to be mostly converged for N ~ 40. The flux spectrum for N of 20 and 40 are shown below. (A suitable metric for quantifying the convergence could be the L2 norm of the frequency spectra using the reference spectra at N of 200.)

    The next step is to reproduce these results using the deterministic approach outlined in (2).

    led_sim

    py
    import meep as mp
    from meep.materials import Ag

    import numpy as np
    import random

    import matplotlib
    matplotlib.use('agg')
    import matplotlib.pyplot as plt

    import argparse
    parser = argparse.ArgumentParser()
    parser.add_argument('-nr', type=int, default=20, help='number of flux calculations')
    args = parser.parse_args()

    resolution = 50

    dpml = 1.0
    dair = 1.0
    hrod = 0.7
    wrod = 0.5
    dglass = 3.0
    dAg = 0.5

    sx = 1.1
    sy = dpml+dair+hrod+dglass+dAg

    cell_size = mp.Vector3(sx,sy)

    pml_layers = [mp.PML(direction=mp.Y,
                         thickness=dpml,
                         side=mp.High)]

    fcen = 1.0
    df = 0.1
    nfreq = 51
    ndipole = 10

    geometry = [mp.Block(material=mp.Medium(index=3.45),
                         center=mp.Vector3(0,0.5*sy-dpml-dair-0.5*hrod),
                         size=mp.Vector3(wrod,hrod,mp.inf)),
                mp.Block(material=mp.Medium(index=3.45),
                         center=mp.Vector3(0,0.5*sy-dpml-dair-hrod-0.5*dglass),
                         size=mp.Vector3(mp.inf,dglass,mp.inf)),
                mp.Block(material=Ag,
                         center=mp.Vector3(0,-0.5*sy+0.5*dAg),
                         size=mp.Vector3(mp.inf,dAg,mp.inf))]

    def compute_flux():
        sources = []
        for n in range(ndipole):
            sources.append(mp.Source(mp.GaussianSource(fcen,fwidth=df),
                                     component=mp.Ez,
                                     center=mp.Vector3(sx*(-0.5+n/ndipole),-0.5*sy+dAg+0.3*dglass),
                                     amplitude=np.exp(1j*2*np.pi*random.random())))

        sim = mp.Simulation(cell_size=cell_size,
                            force_complex_fields=True,
                            resolution=resolution,
                            k_point=mp.Vector3(),
                            boundary_layers=pml_layers,
                            geometry=geometry,
                            sources=sources)

        tran = sim.add_flux(fcen,df,nfreq,mp.FluxRegion(center=mp.Vector3(0,0.5*sy-dpml),size=mp.Vector3(sx)))

        sim.run(until_after_sources=500)

        tran_flux = mp.get_fluxes(tran)
        freqs = mp.get_flux_freqs(tran)
        sim.reset_meep()
        return freqs, tran_flux

    nrun = args.nr
    tran_fluxes = np.zeros((nfreq,nrun))

    for m in range(nrun):
        freqs, tran_fluxes[:,m] = compute_flux()

    flux_avg = np.mean(tran_fluxes,axis=1)

    plt.figure()
    plt.plot(freqs,flux_avg,'bo-')
    plt.xlabel('frequency')
    plt.ylabel('flux in +y direction (averaged)')
    plt.title('num. dipoles: {}, num. flux calculations: {}'.format(ndipole,nrun))
    plt.savefig('led_avg_flux_ndipole{}_nrun{}.png'.format(ndipole,nrun))


    led_avg_flux_ndipole10_nrun20

    led_avg_flux_ndipole10_nrun40

    点赞 评论 复制链接分享
  • weixin_39874809 weixin_39874809 4月前

    The easiest thing would be to nondimensionalize: compute the same thing for a structure with no surface-corrugation, and take the ratio.

    Then, for approach (2), you don't need any fancy normalization — just use the same gaussian sources for all of the point-source cancellation, and the source spectrum will cancel when you normalize against the flat-surface emission.

    点赞 评论 复制链接分享

相关推荐
